ชุดแบตเตอรี่ | ข้อมูลจำเพาะ | สังเกต | |
Model No. | AIN36100 | / | |
ประเภทแบตเตอรี่ | 36V LiFEPO4 battery | / | |
แรงดันไฟฟ้าที่กำหนด | 36V / 38.4Volt | customizable Voltage | |
Charge Cut-off (BMS protection) | 45volt±0.35volt | / | |
Discharge Cut-off (BMS protection) | 27.6volt±1.2volt | / | |
Standard / Nominal Capacity | 105 อา | customizable | |
Approx. Weight | 29kg | / | |
Pack Type | 12S1P | customizable | |
Reserve Minutes @0.2C 25℃ / | 300minutes | / | |
แรงดันไฟฟ้าในการทำงาน | 27.6volt~43.8volt | customizable | |
กระแสไฟสูงสุด | 300A±25A within 5second | customizable | |
ความต้านทาน | ≤10mΩ | / | |
Built-in Cell Model | Prismatic @ 100Ah/50Ah/300Ah | customizable | |
อุณหภูมิการชาร์จ | 32(℉)~122(℉) | / | |
ปล่อยอุณหภูมิ | -4(℉)~140(℉) | / | |
วงจรชีวิต | 4000cycle (80%DOD) | / | |
Max Cont. discharge current | 100A | customizable | |
วิธีการชาร์จ | CC / CV | customizable | |
Built-in BMS system | ใช่ | / | |
BMS Protection Type | Over-Charge, Over-Dishcarge, Over-Voltage, Over-Current, Short-Circuit, Auto-reset | / | |
BMS Balance Type | Active Auto-Balancing | / | |
ขนาด | 53*22*17cm | customizable | |
Connection Type | Modular Pack welding or laser spot welding | / | |
BMS | Balanced Current ( BMS ) | 20~30mA | / |
Balanced voltage | 3.6volt | / | |
Over Charge Protection | 3.75±0.0.3v / cell | / | |
Release Voltage for overcharge | 3.60±0.05v | / | |
Rated Charge Current Protection | 100A | customizable | |
Detection delay (over-Charge) | 1000mS | / | |
Short circuit trigger condition | external load short circuit | / | |
Detection delay (short-circuit) | 200uS | / | |
Over-Discharge Cut-Off Voltage | 2.1V±0.1V / cell | / | |
Over-Discharge Release Voltage | 2.3V±0.1v | / | |
Discharge protection current | 300 (10mS) | / | |
Rated Discharge Current | ≤100A | customizable | |
Release condition (short circuit & over discharge) | Disconnect Load & Charge Activation | / | |
Detection delay (over-discharge ) | 1000mS | / | |
Communication interface | Bluehost / RS485 / RS232 GPS protocol port for Choice | customizable | |
Temperature control protection | Discharge protection: 167 (℉)±40 (℉) | / | |
อุณหภูมิในการทำงาน | -4(℉) ~ 176(℉) | / | |
Over Heat Temperature Protection(Charge&Dishcarge) | 167(℉)±41(℉) | / | |
High temperature release value(Charge&Dishcarge) | 127.4(℉) | / | |
ตัวบ่งชี้ที่นำ | Display Value | Voltage / Capacity percent / Work Temperature | customizable |
ใบรับรอง | CE, MSDS, CB-SG, UN38, UL1642 | customizable | |
Outside Battery Box | Outside Protection Box | Stainless steel outer box | Available ABS BOX Series |
IP Level | IP65 | customizable | |
Aging | Lead time | 5-15days normally | rely on the order quantity |
Shipment Time | 7-12days by express, 15~35days by Air, sea and rail transportation | / | |
Quality Assurance | การประกัน | 3 year / 36 months | / |
Product advantages
การใช้งาน
1) Energy Storage: UPS, backup, power station.
2) EV: Golf trolleys, Electric scooters.
3) Solar Energy Storage Systems, Wind Energy Storage,Solar/Storage Home System, Solar Street Light.
4) สถานีฐานโทรคมนาคม
5) Marine Boat.
6) UPS (Uninterrupted Power Supply).
7) General Energy Storage (Such as Back-up Power, Miner's lamp, portable power supply, digital products, etc.)
ที่เกี่ยวข้อง LFP แบตเตอรี่
โรงงานของเรา
การบรรจุและการจัดส่ง
A1: Yes, we are the original factory, specializing in NiMH battery and lithium battery for more than 10 years.
Q2: ฉันสามารถสั่งซื้อตัวอย่างได้หรือไม่?
A2: ใช่เรายอมรับคำสั่งซื้อตัวอย่างเพื่อทดสอบและตรวจสอบคุณภาพแบตเตอรี่สามารถทำได้ตามต้องการ
Q3: คุณมี MOQ หรือไม่?
A3: ไม่ จำกัด แต่ยิ่งคุณสั่งมากเท่าไหร่คุณก็จะได้ราคาที่ดีขึ้นเท่านั้น
Q4: วันที่จัดส่งของคุณคืออะไร?
A4: โดยปกติ 3-5 สัปดาห์หลังจากยืนยันการชำระเงินตามปริมาณการสั่งซื้อที่แน่นอน
Q5: คุณมักใช้วิธีการจัดส่งแบบใด?
A5: โดยทั่วไปปริมาณเล็กน้อยผ่านทางด่วนหรือทางอากาศ ปริมาณการสั่งซื้อจำนวนมากทางทะเล
Q6: คุณให้บรรจุภัณฑ์ประเภทใด?
A6: Standard export carton or wooden case according to battery size and weight, the package will be strong enough for long-distance transport.
เราหวังเป็นอย่างยิ่งที่จะสร้างความสัมพันธ์ความร่วมมือระยะยาวกับคุณหากคุณมีคำถามใด ๆ โปรดอย่าลังเลที่จะติดต่อเรา!
