ข้อมูลจำเพาะ
ITEMS | 12v 100ah Lifepo4 battery |
Cell ype | LiFePo4 Cells |
แรงดันไฟฟ้าที่กำหนด | 12.8 โวลต์ |
ความจุที่กำหนด | 100 อา |
การป้องกัน | BMS (without communication) |
Over Discharge Protection Voltage | 14.6V |
Over Charge Protection Voltage | 10.0V |
กระแสไฟต่อเนื่องสูงสุด | 100A |
กระแสไฟฟ้าสูงสุดของ Pulse | 200A (less than 5s) |
Working Temp. Range/℃ | Charge: 0℃~60℃ |
Discharge: -10℃~60℃ | |
อุณหภูมิในการจัดเก็บ | Less than 1 year: -10℃~25℃ |
Less than 3 months: -10℃~40℃ | |
Less than 30 days: -10℃~45℃ | |
ตัวเชื่อมต่อ | 300 pure copper connector (can be customized) |
Size(L×W×H)/mm | 305*175*195 (±5) |
Battery pack Weight | 13.5 kg |
Quality Warranty | 3 ปี |
The data on the above is our standard matched pack. Size/max continuous discharge current/ max discharge current are adjustable based on customer's detail requirement. Different current needs different BMS, so please specify the charge/ discharge current for moudle customize, also the cost of battery pack would be slightly different based on BMS selection. |
1. A grade LiFePO4 cells with long cycle life
2. BMS built in with over charge, over discharge, over current, over temperature protection etc.
3. Sorting before batteries were assembled, to make sure every single battery pack was assembled by batteries with same Volt, capacity and resistance.
4. An idea choice for solar energy storage, electric scooter, electric boat etc.
5. Perfect to replace lead acid battery
6. Cover the battery with epoxy board before packaging, to protect battery from hit and high temperature. Epoxy board is a flame-retardant material, can prevent battery on fire or explosion.
7.All the battery pack will be cycle aging. Before we put the battery pack in to packing box or next step assembly, we charge and discharge the battery pack to text it's parameters to make sure it can work well.
8. Well trained employee,every employ will be trained for two weeks before he(or she) goes to work at production line, make sure he(or she) can complete every work program accurately. Payment Term: 30% TT in Advance, 70% balance before shipment.
ที่เกี่ยวข้อง LiFePO4 แบตเตอรี่ Our Company
Q1: ฉันสามารถหาตัวอย่างเพื่อทดสอบได้หรือไม่? และระยะเวลาในการสั่งซื้อตัวอย่างคืออะไร?
Yes,we can supply samples in 5-7 days depending on different product items and clients' requirement. For normal in stock product,2~5 days; For customized product,3~7days depends on requirements.
Q2: การรับประกันสินค้าคืออะไร?
1 ~ 10 ปีเนื่องจากผลิตภัณฑ์ของเรากว้าง Minimum12v 40Ah ระบบจัดเก็บพลังงานคอนเทนเนอร์สูงสุด 2MW ผลิตภัณฑ์ที่แตกต่างกันมีการรับประกันที่แตกต่างกันโปรดตรวจสอบก่อนสั่งซื้อ
Q3: อะไรคือข้อได้เปรียบของ บริษัท ของคุณ?
เราเป็นโรงงานโดยตรงมีประสบการณ์มากมายในการปรับแต่งชนิดของไฟฟ้าแรงสูงความจุสูงชุดแบตเตอรี่ประสิทธิภาพสูงสำหรับคาราวาน RV 12v / 24v / 48v / 80v รถยกไฟฟ้ารถกอล์ฟทะเล AGV การเปลี่ยนแบตเตอรี่กรดตะกั่ว ที่เก็บพลังงานแสงอาทิตย์ในบ้าน, รถแทรกเตอร์เครื่องบิน 384V / 460V / 614V, รถบรรทุกหนัก, รถไฟเหมือง, แหล่งจ่ายไฟ DC 110v / 220v, ตู้ ESS, คอนเทนเนอร์ ESS และอื่น ๆ สามารถให้การสนับสนุนด้านเทคโนโลยีที่ดีที่สุดและเป็นมืออาชีพแก่คุณ
Q4: คุณยอมรับ OEM / ODM หรือไม่
ใช่ยินดีต้อนรับ!
Q5: ระยะเวลาในการสั่งซื้อจำนวนมากคืออะไร?
โดยทั่วไปประมาณ 7 ~ 20 วันขึ้นอยู่กับรายการที่แตกต่างกันหลังจากได้รับเงินดาวน์และการยืนยันเกี่ยวกับตัวอย่าง
Q6: เงื่อนไขการชำระเงินคืออะไร?
ตัวอย่างการชำระเงินยอมรับ Paypal สหภาพตะวันตกสัญญาและสั่งซื้อจำนวนมากโดย T / T
Q7: ใบรับรองประเภทใดที่สามารถเสนอได้?
CE, RoHS, UN38.3, MSDS ฯลฯ หากต้องการ IEC-62133, PSE และอื่น ๆ โปรดปรึกษากับเรา
